Mixing capacity:
20 - 50 l / min

Maximum grain size:
6 mm

Connected load:
400 V, 3 Ph, 50 Hz, 4 kW

Drive motor:
4 kW, 280 rpm

Mixing tube:
rubber mixing tube

Base:
removable

Roles:
2 roles

Water connection:
Geka DN12 (1/2 ") - 2.5 bar operating pressure

Operation and control:
start / stop

Dimensions:

Filling height:
1,000 mm

Container volume:
110 liters ~ 3.5 bags (30 kg each)

Spout height:
650 mm

Length / width / height:
1,650 / 650 / 1,000 mm

Total weight:
123 kg

Basic equipment package:

Water flow meter:
with manometer

Dosing shaft:
35 l / min

Booster pump:
not included

Connection cable:
not included

Water / air hose:
not included

Silo / container
handover : possible using a handover hood

Mixing capacity:

20 - 35 l / min

Maximum grain size:
4 mm

Connected load:
400 V, 3 Ph, 50 Hz, 4 kW

Drive motor:
4 kW, 280 rpm

Mixing tube:
rubber mixing tube

Base:
removable

Roles:
2 roles

Water connection:
Geka DN12 (1/2 ") - 2.5 bar operating pressure

Operation and control:
start / stop

Dimensions:

Filling height:
1,000 mm

Container volume:
110 liters ~ 3.5 bags (30 kg each)

Spout height:
650 mm

Length / width / height:
1,650 / 650 / 1,000 mm

Total weight:
123 kg

Basic equipment package:

Water flow meter:
with manometer

Dosing shaft:
35 l / min

Booster pump:
not included

Connection cable:
not included

Water / air hose:
not included

Silo / container
handover : possible using a handover hood
