Delivery rate max .:
35 l / min

Delivery distance up to: 15 m for DN25 (230 V)
30 m for DN25 (400 V)
50 m for DN35 (400 V)

Connected load : 230/400 V, 1/3 Ph, 50 Hz, 5.5 kW
Control voltage: 42 V

Drive:
Pump motor: 5.5 kW, 400 rpm
2-stage gear with tilt
switch Cell wheel motor : 0.3 kW, 12 rpm

Mixing tube:
rubber mixing tube with interchangeable flange

Mixing helix:
BIONIK G 4 machine plaster

Mortar outlet with mortar pressure gauge:
DN35 female part

Castors:
2 swivel castors, 2 double-stop swivel castors

Water connection:
Geka DN19 (3/4 ") - 2.5 bar operating pressure

Operation and control:
start / stop including water pump control and stepless speed control at 230 V.

Filling height:
910 mm

Container volume:
145 liters ~ 5 bags (each 30 kg)

Length / width / height:
1,200 / 720 / 1,530 mm

Total weight:
290 kg

Pump unit : SD 6–3 slimline · 20 l / min · 25 bar

Mortar
hose : RONDO DN25 - 10 m

Adapter
coupling : DN35 male part | DN25 male part

Water pump to increase pressure:
AVO 500
230 V, 1 Ph, 50 Hz, 0.37 kW

Water flow meter:
150 - 1,500 l / h

Air compressor:
COMP P-200, 230 V, 1 Ph,
50 Hz, 0.5 kW, 200 l / min - max. 3.4 bar with pressure cut-off

Spraying device / fine plastering device : DN25-360 ° S14 200 Geka

Connection
cable : adapter cable RED 5-32 A | BLU 2-16 A - 1 m

Water / air hose:
DN12 (1/2 ") Ewo | Geka - 11 m
